5" Open Frame HDMI Display
5-inch IPS HDMI display, 800 x 480, 950 cd/m² Enhanced Brightness. Ideal for industrial HMI, embedded systems, kiosk and automation applications. — DigiWise
The 5" Open Frame HDMI Display is a 5-inch IPS display module with 800 x 480 resolution and HDMI connectivity. It delivers 950 cd/m² (nits), rated Enhanced Brightness, across a wide -30 ~ +70 (℃) operating range. With a 16:9 aspect ratio and IPS wide viewing angles, it suits industrial, embedded and HDMI display applications.
Specifications
| Model number | OF-050WIHXXXXXXXXX |
|---|
| Size | 5" |
|---|
| Resolution | 800 x 480 |
|---|
| Interface | HDMI |
|---|
| Brightness | 950 cd/m² (nits) |
|---|
| Touch | Non-touch |
|---|
| Active display width | 108 mm |
|---|
| Aspect Ratio | 16:9 |
|---|
| Viewing Direction | IPS |
|---|
| Outline Dimension | 144.7 x 109.2 x 22.9 mm / 5.70 x 4.30 x 0.90 inch |
|---|
| Active Area | 108 x 64.8 mm / 4.25 x 2.55 inch |
|---|
| Operating Temperature | -30 ~ +70 (℃) / -22 ~ +158 (℉) |
|---|
| Storage Temperature | -30 ~ +80 (℃) / -22 ~ +176 (℉) |
|---|
| Recommended Accessories | HDMI cable: 315-H019A1050A (500mm / 19.69 inch) / 315-H019A10A1A (1000mm / 39.37 inch) |
|---|
Highlights
0.135 mm pitch — about 188 PPI
800 x 480 across a 108 x 64.8 mm active area, on square 0.135 mm pixels.
950 cd/m² — enhanced brightness
Enhanced Brightness class, about double a standard-brightness module, on an IPS panel that holds its colour off-axis.
-30 ~ +70 (℃) operating range
Operates down to -30 ℃, with storage rated to +80 ℃.
6H hard-coated PMMA front
A 6H hard-coated lens over the panel.
Standard HDMI input
The same input a monitor takes, with the driver board and LED backlight driver already fitted.
Open-frame chassis, 22.9 mm deep
A 144.7 x 109.2 x 22.9 mm module in an open frame, with the backlight driver already on the board.
